Humidity, Clouds, Precipitation and Cyclones: GK Notes

Exam notes on humidity, condensation, cloud types, the three kinds of rainfall and tropical and temperate cyclones, with the IMD grades and solved questions.

By · Published · 5 min read

Humidity, Clouds, Precipitation and Cyclones: GK Notes — GK24 title card
Humidity, Clouds, Precipitation and Cyclones: GK Notes — GK24 title card

Water vapour is a small part of the atmosphere by volume but it decides the weather. Humidity, condensation, cloud and rainfall together make one chain of cause and effect, and the tropical cyclone is that chain at its most violent. Examiners draw questions from every link: the three ways of measuring humidity, the names of the clouds, the three kinds of rainfall, the conditions a cyclone needs, its structure, the names it carries in different seas and the wind-speed grades the India Meteorological Department uses.

Humidity and the way it is measured

Humidity is the water vapour present in the air, and it is stated in three ways. Absolute humidity is the actual weight of water vapour in a given volume of air, expressed in grams per cubic metre; it falls from the equator towards the poles and from the sea towards the interior. Specific humidity is the weight of water vapour in a unit weight of air, expressed in grams per kilogram, and it does not change when the air expands or contracts, which is why meteorologists prefer it. Relative humidity is the ratio of the water vapour actually present to the maximum the air can hold at that temperature, expressed as a percentage.

The capacity of air to hold vapour rises with temperature, so relative humidity falls when air is heated and rises when it is cooled, even though the quantity of vapour has not changed. Air holding all the vapour it can at a given temperature is saturated, and the temperature at which a given sample becomes saturated is its dew point. Relative humidity is measured with a hygrometer, and the wet and dry bulb thermometers of a psychrometer are the usual working instrument.

TermWhat it statesUnit
Absolute humidityVapour in a given volume of airGrams per cubic metre
Specific humidityVapour in a unit weight of airGrams per kilogram
Relative humidityVapour present against capacity at that temperaturePercentage
Dew pointTemperature at which the air becomes saturatedDegree Celsius

Condensation, clouds and precipitation

When air is cooled below its dew point the vapour condenses on dust, smoke and salt particles that act as nuclei. The form the condensation takes depends on where it happens and on the temperature. Dew forms on cool surfaces when the dew point is above freezing; frost forms as ice crystals when the dew point is below freezing; fog and mist are condensation around nuclei near the ground, fog being the denser of the two; and clouds are condensation in the free air.

Clouds are classified by height and by form. The high clouds, from about six to twelve kilometres, are cirrus, cirrostratus and cirrocumulus; cirrus is thin, feathery and made of ice crystals. The middle clouds, from about two to six kilometres, are altostratus and altocumulus. The low clouds, up to about two kilometres, are stratus, stratocumulus and nimbostratus, the last being the thick dark sheet that gives steady rain. Cumulus and cumulonimbus grow vertically through these levels; the cumulonimbus, the tallest of them, brings thunder, lightning, heavy showers and hail, and is the cloud of the thunderstorm.

Precipitation is the water that falls back to the surface, as rain when the drops are liquid, as snow when the vapour condenses directly into crystals below freezing, as sleet when raindrops freeze while falling through a cold layer, and as hail when pellets of ice are carried up and down inside a cumulonimbus until they are heavy enough to fall. Rainfall itself is of three types. Convectional rainfall comes from air heated at the surface, rising, cooling and condensing, and gives the equatorial belt its brief, heavy afternoon showers. Orographic or relief rainfall falls where moist air is forced to rise over a mountain barrier, wetting the windward slope and leaving a dry rain-shadow on the leeward side. Cyclonic or frontal rainfall comes where a warm air mass is forced over a cold one along a front, and is typical of the temperate latitudes.

Tropical cyclones

A tropical cyclone is an intense low-pressure system of the warm seas, with winds spiralling inward anticlockwise in the northern hemisphere and clockwise in the southern. It needs a large sea surface with a temperature above about twenty-seven degrees Celsius, abundant moisture, a sufficient Coriolis force, which is why none forms within about five degrees of the equator, small variation of wind with height and divergence of air above the low-pressure centre.

At the centre is the eye, a calm and nearly cloudless column of descending air some tens of kilometres across; around it is the eye wall, a ring of towering cumulonimbus where the strongest winds and the heaviest rain occur, and beyond that the spiral rain bands. The system weakens quickly after landfall because its supply of warm moist air is cut off. The same storm is called a hurricane in the Atlantic and the eastern Pacific, a typhoon in the north-western Pacific and the China Sea, a cyclone in the Indian Ocean, a willy-willy in Australia and a baguio in the Philippines. The India Meteorological Department is the regional body that names the storms of the north Indian Ocean and grades them by sustained wind speed.

GradeSustained wind speed
Depression31 to 49 kilometres per hour
Deep depression50 to 61 kilometres per hour
Cyclonic storm62 to 87 kilometres per hour
Severe cyclonic storm88 to 117 kilometres per hour
Very severe cyclonic storm118 to 166 kilometres per hour
Extremely severe cyclonic storm167 to 221 kilometres per hour
Super cyclonic storm222 kilometres per hour and above

Temperate cyclones and other systems

A temperate or extra-tropical cyclone forms along the front where a cold polar air mass meets a warm subtropical one, between about thirty-five and sixty-five degrees latitude. It is larger than a tropical cyclone, has no eye, moves from west to east, lasts longer, brings slow and widespread rain rather than a short violent burst, and is commonest in winter. The western disturbances that bring winter rain to north-west India are systems of this kind. An anticyclone is the opposite case, a high-pressure system with winds blowing outward, clockwise in the northern hemisphere, and it brings clear and settled weather. A tornado is a small, extremely violent funnel of whirling air over land, and the same funnel over water is a waterspout.

Exam Point of View

Three kinds of question come from this topic. The first is definition with unit: which humidity is a percentage, what the dew point is, which instrument measures humidity, where a hydrometer is the planted trap for a hygrometer. The second is classification: clouds by height, the cloud of the thunderstorm, the three types of rainfall, and the local names of the cyclone, which are asked both as a direct question and as a match-the-list. The third is the cyclone itself: the eye and the eye wall, the conditions of formation including the Coriolis rule about five degrees, the wind-speed grades of the India Meteorological Department, and the differences between a tropical and a temperate cyclone. Recent storms and the coast each one struck are also asked, so keep the Arabian Sea and Bay of Bengal names apart.

Important Facts

Unit of absolute humidityGrams per cubic metre
Unit of specific humidityGrams per kilogram
Instrument for relative humidityHygrometer, commonly a wet and dry bulb psychrometer
Height of high cloudsAbout 6 to 12 kilometres
Thunderstorm cloudCumulonimbus
Cloud of steady, continuous rainNimbostratus
Minimum sea surface temperature for a tropical cycloneAbout 27 degrees Celsius
Why no cyclone forms at the equatorThe Coriolis force is zero there and too weak within about 5 degrees
Super cyclonic stormSustained wind of 222 kilometres per hour and above
Latitudes of temperate cyclonesAbout 35 to 65 degrees, moving west to east

Practice MCQs on this topic

Q3.GeographyAsked in: Uttar Pradesh · UPPSC Civil Services General StudiesMedium

Match List - I with List - II and select the correct answer using the codes given below the lists: List - I (Tropical cyclones) List - II (Country) A. Baguio 1. Australia B. Hurricanes 2. China C. Typhoons 3. Philippines D. Willy-Willies 4. United States of America

  1. A.A) 3, B) 4, C) 1, D) 2
  2. B.A) 3, B) 4, C) 2, D) 1
  3. C.A) 2, B) 3, C) 4, D) 1
  4. D.A) 2, B) 1, C) 3, D) 4
Show answer
Correct answer: B. A) 3, B) 4, C) 2, D) 1

The local names of the tropical cyclone are a standing favourite: baguio belongs to the Philippines, hurricane to the United States and the wider Atlantic and Caribbean region, typhoon to China and the north-western Pacific, and willy-willy to Australia.

Q6.GeographyMedium

Which of the following is expressed as a percentage?

  1. A.Absolute humidity
  2. B.Relative humidity
  3. C.Specific humidity
  4. D.Dew point
Show answer
Correct answer: B. Relative humidity

Relative humidity compares the water vapour actually present in the air with the maximum amount the air could hold at that temperature, so it is a ratio and is stated as a percentage; air at a hundred per cent relative humidity is saturated.

Q7.GeographyMedium

Which cloud is known for bringing thunder, lightning and hail, and is called the thunderstorm cloud?

  1. A.Cirrus
  2. B.Altostratus
  3. C.Stratus
  4. D.Cumulonimbus
Show answer
Correct answer: D. Cumulonimbus

The cumulonimbus is a cloud of great vertical extent that can rise from near the ground almost to the top of the troposphere, and the strong updraughts inside it produce thunder, lightning, heavy showers and hail; it is the cloud of the thunderstorm and the eye wall of a cyclone…

Q8.GeographyMedium

The brief, heavy afternoon showers of the equatorial belt are an example of which type of rainfall?

  1. A.Convectional rainfall
  2. B.Orographic rainfall
  3. C.Frontal rainfall
  4. D.Cyclonic rainfall
Show answer
Correct answer: A. Convectional rainfall

In the equatorial belt the ground is strongly heated through the morning, the warm moist air rises in powerful convection currents, cools as it rises, condenses into towering cumulonimbus and falls as a short, very heavy shower in the afternoon, which is why it is nicknamed four o'clock rain.

Q9.GeographyHard

Tropical cyclones do not form within about five degrees of the equator because

  1. A.the sea surface temperature there is too low
  2. B.there is not enough moisture in the air
  3. C.the Coriolis force is too weak to set the air spinning
  4. D.the air there is always descending
Show answer
Correct answer: C. the Coriolis force is too weak to set the air spinning

The Coriolis force, which arises from the rotation of the earth, is zero at the equator and very weak for a few degrees on either side, so converging air cannot be deflected into the spiral that makes a cyclone; the belt within about five degrees of the equator is therefore…

Q10.GeographyHard

According to the classification used by the India Meteorological Department, a storm is called a super cyclonic storm when the sustained wind speed is

  1. A.62 to 87 kilometres per hour
  2. B.88 to 117 kilometres per hour
  3. C.118 to 166 kilometres per hour
  4. D.222 kilometres per hour and above
Show answer
Correct answer: D. 222 kilometres per hour and above

The India Meteorological Department grades a system of the north Indian Ocean by its sustained wind speed, and the highest grade, the super cyclonic storm, begins at two hundred and twenty-two kilometres per hour.

Q11.GeographyMedium

Which of the following is true of a temperate cyclone but not of a tropical cyclone?

  1. A.It forms along a front where two air masses of different temperature meet
  2. B.It has a calm central eye surrounded by a wall of cumulonimbus
  3. C.It weakens rapidly as soon as it crosses the coast
  4. D.It cannot form within five degrees of the equator
Show answer
Correct answer: A. It forms along a front where two air masses of different temperature meet

A temperate or extra-tropical cyclone is a frontal system: it forms between about thirty-five and sixty-five degrees latitude where a cold polar air mass meets a warm subtropical one, and the warm air is forced to rise along the front, giving slow and widespread rain over a large area.

Frequently Asked Questions

What is the difference between absolute, specific and relative humidity?

Absolute humidity is the weight of water vapour in a given volume of air, in grams per cubic metre. Specific humidity is the weight of vapour in a unit weight of air, in grams per kilogram, and it stays the same when the air expands or contracts, which is why meteorologists use it. Relative humidity is the ratio of the vapour present to the maximum the air can hold at that temperature, stated as a percentage; it falls when the air is heated.

Why does a tropical cyclone weaken after it crosses the coast?

Its energy comes from the latent heat released when water vapour from a warm sea condenses in the rising air at its centre. Over land the supply of warm moist air is cut off and friction with the rough surface slows the inflowing winds, so the pressure gradient weakens and the system decays into a depression within a day or two, although it may still bring very heavy rain inland.

What is the difference between a tropical and a temperate cyclone?

A tropical cyclone forms over warm seas between about five and thirty degrees latitude, has a calm eye and a wall of cumulonimbus, is small but violent, lasts a few days and dies quickly over land. A temperate cyclone forms along a front between two air masses between about thirty-five and sixty-five degrees, has no eye, is much larger, moves from west to east, brings slow widespread rain and is commonest in winter.

What are the three types of rainfall?

Convectional rainfall, where surface heating lifts the air, as in the afternoon showers of the equatorial belt; orographic or relief rainfall, where a mountain barrier forces moist air to rise, wetting the windward slope and leaving a rain shadow to leeward; and cyclonic or frontal rainfall, where warm air is forced over cold air along a front, the slow widespread rain of the temperate latitudes.

What is the eye of a cyclone?

The eye is the roughly circular central region of a tropical cyclone, a few tens of kilometres across, where the air descends, the pressure is lowest, the winds are light and the sky is nearly clear. It is ringed by the eye wall, a band of towering cumulonimbus with the strongest winds and heaviest rain, so a place on the storm's track gets violent weather, a lull, and then violent weather from the opposite direction.
