Circulatory and Excretory Systems: Heart, Blood and Kidney

Exam notes on the human circulatory and excretory systems: blood, the heart and its valves, arteries and veins, blood groups, the nephron and urine formation.

By · Published · 6 min read

Circulatory and Excretory Systems: Heart, Blood and Kidney — GK24 title card
Circulatory and Excretory Systems: Heart, Blood and Kidney — GK24 title card

The body is a crowd of cells that can neither fetch their own food nor throw out their own waste. Two systems do it for them. The circulatory system is a closed network of a pump, tubes and a fluid that carries oxygen, digested food, hormones and heat to every cell; the excretory system filters the blood and throws out the nitrogenous waste that cell chemistry leaves behind. Examiners return to this chapter every year because almost every fact in it is a name, a number or a pairing that can be asked in one line: which chamber, which valve, which hormone, which part of the nephron.

Blood, the fluid that carries everything

Blood is a connective tissue and makes up about seven per cent of body weight, roughly five to six litres in a healthy adult. A little over half of it is plasma, a straw coloured liquid that is about ninety per cent water and carries proteins, salts, glucose and wastes; the rest is the formed elements. Red blood cells, the erythrocytes, are biconcave discs that lose their nucleus as they mature in mammals, which is why they can pack in more haemoglobin. Haemoglobin is an iron containing pigment, and the iron is what binds oxygen. A red cell lives about one hundred and twenty days, is made in the red bone marrow and is broken down in the spleen, which is therefore called the graveyard of red blood cells. White blood cells are fewer, keep their nucleus and defend the body; neutrophils are the most numerous of them and basophils the rarest. Platelets, or thrombocytes, are cell fragments that begin the clotting of blood, in which the soluble plasma protein fibrinogen is turned into threads of insoluble fibrin. Vitamin K is needed for clotting, and heparin is the body's own anticoagulant.

The heart and the double circulation

The human heart is a muscular organ about the size of a closed fist, placed in the thoracic cavity slightly to the left and wrapped in a double membrane called the pericardium. It has four chambers: two thin walled atria above and two thick walled ventricles below. The left ventricle has the thickest wall of all, because it must push blood to the whole body. Valves make the flow one way. The tricuspid valve guards the opening between the right atrium and the right ventricle, the bicuspid or mitral valve the opening on the left, and semilunar valves stand at the mouths of the pulmonary artery and the aorta.

The beat does not come from a nerve. The sino-atrial node in the wall of the right atrium sets the rhythm on its own and is called the pacemaker of the heart; the impulse passes to the atrio-ventricular node, then along the bundle of His and the Purkinje fibres into the ventricles. A resting adult heart beats about seventy-two times a minute and pumps roughly five litres of blood in that minute. Blood pressure is written as systolic over diastolic and is measured with a sphygmomanometer; the electrical activity of the heart is recorded as an electrocardiogram.

Blood passes through the heart twice in one complete round of the body, which is called double circulation. In the pulmonary circuit, deoxygenated blood leaves the right ventricle by the pulmonary artery for the lungs and returns oxygenated by the pulmonary veins. This gives the two famous exceptions: the pulmonary artery is the only artery that carries deoxygenated blood and the pulmonary veins are the only veins that carry oxygenated blood. In the systemic circuit the left ventricle sends blood into the aorta, the largest artery, and it comes back through the venae cavae. William Harvey described this circulation in 1628.

VesselDirectionBlood carried
ArteryAway from the heartOxygenated, except the pulmonary artery
VeinTowards the heartDeoxygenated, except the pulmonary veins
CapillaryWithin the tissueSite of exchange, one cell thick
Hepatic portal veinIntestine to liverCarries absorbed food, not to the heart first
Coronary arteryTo the heart muscle itselfIts blockage causes a heart attack

Blood groups and transfusion

Karl Landsteiner worked out the ABO system, the antigens sitting on the red cell surface and the antibodies in the plasma. Group AB has both antigens and no antibody, so it can receive from all and is called the universal recipient; group O has no antigen, so it can be given to all and is called the universal donor. The Rh factor was named after the rhesus monkey in which it was first found; when an Rh negative mother carries an Rh positive child a second time, the child may suffer the disease erythroblastosis foetalis. Lymph is the second circulating fluid, colourless because it has no red cells, and it returns tissue fluid and absorbed fat to the blood.

The excretory system and the nephron

A pair of bean shaped kidneys lies against the back wall of the abdomen, the right one a little lower than the left because the liver takes up room above it. Each kidney has an outer cortex, an inner medulla and a funnel shaped pelvis that opens into the ureter. The working unit is the nephron, and each kidney holds about one million of them. Blood enters the cup shaped Bowman's capsule through a knot of capillaries called the glomerulus, and is pushed through under pressure in a step called ultrafiltration: everything except blood cells and large proteins passes out. The filtrate then travels down the proximal convoluted tubule, the loop of Henle, the distal convoluted tubule and the collecting duct. The proximal tubule does most of the selective reabsorption, taking back all the glucose and amino acids and most of the water, and the loop of Henle sets up the salt gradient that lets the kidney send out concentrated urine. About ninety-nine per cent of the filtrate is reabsorbed, which is why roughly one hundred and eighty litres filtered a day leaves only about one and a half litres of urine.

Hormones do the fine control. Antidiuretic hormone, also called vasopressin, comes from the posterior pituitary and makes the tubule reabsorb more water; when it is deficient the body passes litres of dilute urine, the condition called diabetes insipidus. Aldosterone from the adrenal cortex handles sodium, and renin from the juxtaglomerular cells of the kidney begins the chain that raises falling blood pressure. Urine is about ninety-five per cent water, and its chief nitrogenous waste is urea, which is made not in the kidney but in the liver; its pale yellow colour comes from the pigment urochrome. Animals that excrete mainly urea, such as human beings and other mammals, are called ureotelic; bony fishes are ammonotelic and birds, reptiles and insects are uricotelic, passing out semi-solid uric acid to save water. The kidney is not the only organ of excretion: the skin gives out water, salts and a little urea as sweat, the lungs give out carbon dioxide and water vapour, and the liver passes bile pigments into the gut. When both kidneys fail, the blood is cleaned outside the body by haemodialysis, using a semi-permeable membrane and heparin to stop clotting.

Exam Point of View

Questions fall into five sets. First, the parts of blood: which cell lacks a nucleus, how long a red cell lives, which organ destroys it, which plasma protein makes the clot. Second, the heart: number of chambers, which wall is thickest, which valve lies where, and the pacemaker, where the atrio-ventricular node is offered as a distractor. Third, the two standing exceptions of the pulmonary artery and the pulmonary veins, and the hepatic portal vein that runs from the intestine to the liver. Fourth, blood groups: universal donor and recipient are asked in both directions, so read the stem carefully. Fifth, the nephron in order, the site of ultrafiltration against the site of reabsorption, and the hormone pair antidiuretic hormone with diabetes insipidus set against insulin with diabetes mellitus. A favourite trap is asking where urea is made, since the kidney only removes it.

Important Facts

Volume of blood in an adultAbout 5 to 6 litres, nearly 7 per cent of body weight
Lifespan of a red blood cellAbout 120 days
Graveyard of red blood cellsSpleen, also the largest lymphoid organ
Pigment of red blood cellsHaemoglobin, which contains iron
Most numerous white blood cellsNeutrophils; basophils are the fewest
Protein of clottingFibrinogen, changed into fibrin; vitamin K is needed
Chambers of the heartFour: two atria and two ventricles
Thickest wallLeft ventricle
Pacemaker of the heartSino-atrial node, in the right atrium
Valve on the left sideBicuspid or mitral valve
Only artery with deoxygenated bloodPulmonary artery
Largest artery and largest veinAorta and inferior vena cava
Universal donor and recipientGroup O donates to all, group AB receives from all
Discovery of blood circulationWilliam Harvey, 1628
Unit of the kidneyNephron, about one million in each kidney
Site of ultrafiltrationGlomerulus inside the Bowman's capsule
Main site of reabsorptionProximal convoluted tubule
Hormone that saves waterAntidiuretic hormone, or vasopressin, from the posterior pituitary
Main nitrogenous wasteUrea, made in the liver
Colour of urinePale yellow, from the pigment urochrome

Practice MCQs on this topic

Q1.General ScienceAsked in: Delhi · 29 Sept 2018, Shift 1Easy

Name the filtration units of the excretory system in human.

  1. A.Ureter
  2. B.Nephrons
  3. C.Neurons
  4. D.Urethra
Show answer

Correct answer: B. Nephrons

Explanation

The correct answer is B, nephrons. The nephron is the structural and functional unit of the kidney, and each human kidney holds about one million of them. Blood is pushed into the cup shaped Bowman's capsule through a knot of capillaries called the glomerulus, and there the actual filtration happens: water, salts, glucose, amino acids and urea pass out while blood cells and large plasma proteins are held back. Option A is wrong because the ureter is only the tube that carries formed urine from the kidney down to the urinary bladder; it filters nothing. Option C is wrong because neurons are nerve cells that conduct impulses and belong to the nervous system, not the excretory system; the similar sound of nephron and neuron is exactly the trap in this question. Option D is wrong because the urethra is the last passage through which urine leaves the body. Remember the order: nephron filters, ureter carries, bladder stores, urethra releases.

Q2.General ScienceMedium

Which of the following is the only artery in the human body that carries deoxygenated blood?

  1. A.Aorta
  2. B.Coronary artery
  3. C.Pulmonary artery
  4. D.Carotid artery
Show answer

Correct answer: C. Pulmonary artery

Explanation

The correct answer is C, the pulmonary artery. An artery is defined by direction, not by the kind of blood it holds: it carries blood away from the heart. The pulmonary artery leaves the right ventricle carrying the deoxygenated blood that has come back from the body, and takes it to the lungs to be loaded with oxygen, so it is the single exception to the rule that arteries carry oxygenated blood. Its partner exception is the pair of pulmonary veins, the only veins that carry oxygenated blood. Option A is wrong because the aorta leaves the left ventricle with fully oxygenated blood and is the largest artery of the body. Option B is wrong because the coronary arteries branch off the aorta to feed the heart muscle itself and therefore carry oxygenated blood; their blockage causes a heart attack. Option D is wrong because the carotid arteries carry oxygenated blood up to the head and brain.

Q3.General ScienceEasy

Which blood group is called the universal donor?

  1. A.A
  2. B.B
  3. C.AB
  4. D.O
Show answer

Correct answer: D. O

Explanation

The correct answer is D, group O. In the ABO system the antigens sit on the surface of the red blood cell and the antibodies float in the plasma. Group O red cells carry neither the A antigen nor the B antigen, so there is nothing on them for the recipient's antibodies to attack, and blood of this group can be given to a person of any ABO group. That is why group O is called the universal donor. Option A is wrong because group A cells carry the A antigen and would be destroyed by the anti-A antibody present in the plasma of groups B and O. Option B is wrong for the same reason with the B antigen. Option C is wrong because group AB is the opposite case: its plasma has no anti-A or anti-B antibody, so it can receive from everyone and is called the universal recipient, not the universal donor. Keep the pair straight: O gives to all, AB takes from all.

Q4.General ScienceMedium

The pacemaker of the human heart is the ______.

  1. A.Atrio-ventricular node
  2. B.Sino-atrial node
  3. C.Bundle of His
  4. D.Purkinje fibres
Show answer

Correct answer: B. Sino-atrial node

Explanation

The correct answer is B, the sino-atrial node. The heartbeat is not started by a nerve from the brain; the heart generates its own rhythm, and the patch of specialised tissue that does so fastest sets the pace for the rest. That patch is the sino-atrial node, lying in the wall of the right atrium near the opening of the superior vena cava, and it is therefore called the pacemaker of the heart. Option A is wrong because the atrio-ventricular node only receives the impulse from the sino-atrial node and delays it briefly so that the atria can finish emptying; it can take over as a slower backup pacemaker but is not the normal one. Option C is wrong because the bundle of His is the conducting pathway that carries the impulse from the atrio-ventricular node into the septum between the ventricles. Option D is wrong because the Purkinje fibres are the final branches that spread the impulse through the ventricular muscle. The order to memorise is sino-atrial node, atrio-ventricular node, bundle of His, Purkinje fibres.

Q5.General ScienceMedium

Which organ of the human body is known as the graveyard of red blood cells?

  1. A.Liver
  2. B.Spleen
  3. C.Red bone marrow
  4. D.Pancreas
Show answer

Correct answer: B. Spleen

Explanation

The correct answer is B, the spleen. A red blood cell lives about one hundred and twenty days. As it ages its membrane grows stiff, and the narrow winding channels of the spleen trap such cells so that the macrophages lining them can break the cells down and salvage the iron of their haemoglobin. Because so many worn out red cells are destroyed there, the spleen is called the graveyard of red blood cells; it is also the largest lymphoid organ of the body and acts as a blood reservoir. Option A is wrong because the liver, although it does handle the bilirubin left from broken haemoglobin and turns it into bile pigment, is not the place where the cells are trapped and destroyed. Option C is wrong because the red bone marrow is the opposite: it is the birthplace of red blood cells, not their graveyard. Option D is wrong because the pancreas makes digestive juice and the hormones insulin and glucagon and has no role with red cells at all.

Q6.General ScienceMedium

Urea, the chief nitrogenous waste of human urine, is produced in the ______.

  1. A.Kidney
  2. B.Liver
  3. C.Urinary bladder
  4. D.Spleen
Show answer

Correct answer: B. Liver

Explanation

The correct answer is B, the liver. When the body breaks down more protein than it needs, the amino acids are stripped of their amino group and the ammonia so released is highly poisonous. The liver converts this ammonia into urea, a far less toxic compound, through a series of reactions known as the urea cycle or the ornithine cycle. The urea then travels in the blood to the kidney, which only filters it out and concentrates it in the urine. Option A is wrong for exactly that reason: the kidney removes urea but does not make it, and this separation of the site of manufacture from the site of removal is what the question tests. Option C is wrong because the urinary bladder is only a muscular sac that stores urine until it is passed out. Option D is wrong because the spleen destroys worn out red blood cells and stores blood. Because human beings pass out mainly urea they are described as ureotelic animals, unlike ammonotelic bony fishes and uricotelic birds and reptiles.

Q7.General ScienceHard

In which part of the nephron does the maximum selective reabsorption of glucose and amino acids take place?

  1. A.Bowman's capsule
  2. B.Proximal convoluted tubule
  3. C.Loop of Henle
  4. D.Collecting duct
Show answer

Correct answer: B. Proximal convoluted tubule

Explanation

The correct answer is B, the proximal convoluted tubule. Filtration at the glomerulus is blind: it pushes out useful glucose and amino acids along with the waste. The tubule that immediately follows the Bowman's capsule, the proximal convoluted tubule, has a brush border of microvilli that gives it an enormous surface, and it takes back practically all the glucose and amino acids and about seventy to eighty per cent of the water and salts. Option A is wrong because the Bowman's capsule is the site of ultrafiltration, where the filtrate is formed rather than reabsorbed. Option C is wrong because the loop of Henle does something different: by its counter-current arrangement it builds a salt gradient in the medulla so that concentrated urine can be produced, and it reabsorbs water and sodium, not glucose. Option D is wrong because the collecting duct carries out the last adjustment of water under the influence of antidiuretic hormone. Note the clinical link: glucose appears in the urine only when the blood sugar exceeds what the proximal tubule can carry back.

Q8.General ScienceHard

Deficiency of which hormone causes the disease diabetes insipidus, in which a large quantity of dilute urine is passed?

  1. A.Insulin
  2. B.Antidiuretic hormone
  3. C.Aldosterone
  4. D.Thyroxine
Show answer

Correct answer: B. Antidiuretic hormone

Explanation

The correct answer is B, antidiuretic hormone. Antidiuretic hormone, also called vasopressin, is released by the posterior lobe of the pituitary gland and makes the distal tubule and the collecting duct of the nephron pull water back into the blood. If it is lacking, that water is not recovered and the patient passes litres of very dilute urine and is constantly thirsty, which is the disease diabetes insipidus. Option A is wrong because a shortage of insulin causes diabetes mellitus, an entirely different disorder in which blood glucose rises and sugar spills into the urine; sharing the word diabetes is the trap here. Option C is wrong because aldosterone, from the adrenal cortex, controls the reabsorption of sodium and the excretion of potassium, and its lack disturbs salt balance rather than causing floods of dilute urine. Option D is wrong because thyroxine from the thyroid gland regulates the rate of metabolism, and its deficiency causes cretinism in children and myxoedema in adults. Remember that insipidus means tasteless and mellitus means honey sweet.

Q9.General ScienceMedium

The valve present between the left atrium and the left ventricle of the human heart is called the ______.

  1. A.Tricuspid valve
  2. B.Bicuspid valve
  3. C.Pulmonary semilunar valve
  4. D.Aortic semilunar valve
Show answer

Correct answer: B. Bicuspid valve

Explanation

The correct answer is B, the bicuspid valve. The opening between the left atrium and the left ventricle is guarded by a valve with two flaps or cusps, which is why it is called the bicuspid valve; it is also known as the mitral valve because its shape resembles a bishop's mitre. Its job is to stop blood from being pushed back into the atrium when the powerful left ventricle contracts. Option A is wrong because the tricuspid valve, with three cusps, sits on the other side of the heart, between the right atrium and the right ventricle; swapping the two sides is the commonest error in this question. Option C is wrong because the pulmonary semilunar valve stands at the mouth of the pulmonary artery, where blood leaves the right ventricle for the lungs. Option D is wrong because the aortic semilunar valve stands at the mouth of the aorta, where blood leaves the left ventricle, that is after the bicuspid valve and not between the chambers. A useful memory aid is that the left side has two cusps and the left lung has two lobes.

Q10.General ScienceEasy

Who is credited with the discovery of the circulation of blood in the human body?

  1. A.William Harvey
  2. B.Karl Landsteiner
  3. C.Edward Jenner
  4. D.Robert Koch
Show answer

Correct answer: A. William Harvey

Explanation

The correct answer is A, William Harvey. The English physician William Harvey showed by experiment and measurement that blood is not made afresh and used up in the tissues, as was then believed, but moves in a closed circuit, driven by the heart acting as a pump, and he published this in 1628 in his book on the motion of the heart and blood. Option B is wrong because Karl Landsteiner worked out the ABO blood groups at the beginning of the twentieth century and later helped identify the Rh factor; he explained the kinds of blood, not its movement. Option C is wrong because Edward Jenner introduced vaccination against smallpox using cowpox material and is called the father of immunology. Option D is wrong because Robert Koch identified the bacteria causing tuberculosis and cholera and gave the postulates that link a germ to a disease. A related name worth remembering is Christiaan Barnard, who performed the first human heart transplant.

Frequently Asked Questions

Why is the wall of the left ventricle thicker than that of the right?

Because the two ventricles pump against very different resistances. The right ventricle has only to push blood a short distance to the lungs, which lie beside it and offer little resistance. The left ventricle has to drive blood through the aorta to the brain, the limbs and every other organ, so it must generate a much higher pressure, and a thicker muscular wall is what produces that pressure.

How can group O blood be given to everyone?

Because the antigen that triggers rejection is missing. Antigens A and B sit on the surface of the red cell, and the recipient's plasma antibodies attack whichever antigen is foreign to them. Group O red cells carry neither antigen, so there is nothing for anti-A or anti-B antibodies to fasten on, and the cells survive in a recipient of any ABO group. In practice hospitals match the Rh factor as well and prefer O negative for emergency transfusion.

If the kidney filters about 180 litres a day, why is only about one and a half litres passed as urine?

Because filtration is deliberately wasteful and is followed by careful recovery. The glomerulus pushes out nearly everything small enough to pass, useful substances included. The tubules then reabsorb about ninety-nine per cent of that filtrate, all the glucose and amino acids, most of the salts and almost all the water. What remains is a small volume of concentrated waste, and the amount varies with how much water the body can spare.

What is the difference between diabetes mellitus and diabetes insipidus?

Only the word diabetes, which means passing a large quantity of urine, is common to them. Diabetes mellitus is caused by a shortage of insulin from the pancreas; blood glucose rises and sugar appears in the urine, which is why the name means honey sweet. Diabetes insipidus is caused by a shortage of antidiuretic hormone from the posterior pituitary; the kidney cannot save water and passes a flood of tasteless, very dilute urine.

What does a dialysis machine actually do?

It does the filtering work of failed kidneys outside the body. The patient's blood is passed on one side of a semi-permeable membrane while a dialysing fluid, similar to plasma but free of waste, flows on the other side. Urea, creatinine and excess salts diffuse across into that fluid while blood cells and proteins, being too large, stay behind. Heparin is added so that the blood does not clot on the way, and the cleaned blood is returned to the patient.

Sources

  • Science, Class X, Chapter 6: Life Processes — NCERT
  • Biology, Class XI, Chapter on Body Fluids and Circulation — NCERT
  • Biology, Class XI, Chapter on Excretory Products and their Elimination — NCERT
