Water Conservation and Rainwater Harvesting: Notes and PYQs

Complete notes on water conservation and rainwater harvesting in India: khadin, tanka, johad, zabo, kuhl, modern recharge methods and Jal Shakti schemes.

By · Published · 6 min read

Water Conservation and Rainwater Harvesting: Notes and PYQs — GK24 title card
Water Conservation and Rainwater Harvesting: Notes and PYQs — GK24 title card

Water conservation means using water so that what is withdrawn does not run ahead of what nature puts back, and rainwater harvesting is the oldest way of doing it: catching rain where it falls and keeping it in a tank, a pond or the aquifer below. India has roughly 18 per cent of the world's people but only about 4 per cent of its fresh water, and most of its rain arrives in the four months of the south-west monsoon. Storing that short burst for the dry months is therefore not a modern idea in India but a very old one, and every region built the structure its rainfall and its rock allowed. Examiners like the topic because one set of questions can test geography, environment and government schemes together.

Why India has to conserve water

  • The south-west monsoon, from June to September, brings the bulk of the annual rainfall, so the supply comes in an uneven burst and has to be held back.
  • Groundwater carries most of India's irrigation and rural drinking water, and the Central Ground Water Board grades assessment units as safe, semi-critical, critical and over-exploited according to how far extraction has outrun recharge.
  • Rainfall is also very unequal in space: the north-east and the Western Ghats are drenched while western Rajasthan and the Deccan interior stay dry.
  • Salinity ingress along the coast, fluoride and arsenic in some aquifers and the pollution of rivers cut the usable water further, so conservation is about quality as much as quantity.

Traditional water harvesting structures

The structure and the region it belongs to form the most asked part of this topic. Learn the pairs in the table and the matching questions solve themselves.

StructureRegion or StateWhat it is
KhadinJaisalmer, RajasthanEarthen embankment across the lower slope of a rocky catchment; the crop is grown on the moist bed after the stored runoff drains. Credited to the Paliwal Brahmins of the fifteenth century.
TankaWestern RajasthanCovered underground tank in a courtyard that stores filtered roof and courtyard runoff for drinking
JohadAlwar belt of Rajasthan, HaryanaSmall earthen check dam that ponds monsoon runoff and recharges the wells around it
Baori or stepwellRajasthan, GujaratStepped well cut down to the water table; Rani ki Vav at Patan and Adalaj Vav are the famous ones
KundThar desertSaucer-shaped catchment of lime plaster leading to a covered well
ZingLadakhSmall tank at the end of guiding channels that collect glacier melt water
KuhlKangra, Himachal PradeshGravity channel carrying glacier and stream water to terraced fields
Ahar-PyneSouth Bihar, the old Magadh regionThe pyne is the diversion channel from a river, the ahar the embanked catchment basin at its tail
ZaboKikruma, NagalandImpounding runoff: rain caught on hill tops runs through cattle yards and then to paddy fields that also hold fish
Bamboo drip irrigationKhasi and Jaintia hills, MeghalayaSplit bamboo pipes that carry spring water drop by drop to betel vine and black pepper
Eri and KereTamil Nadu, KarnatakaChains of village tanks, each one overflowing into the next down the slope
SurangamKasaragod, KeralaHorizontal tunnel driven into a laterite hill to tap seepage water
VirdaBanni grassland, KutchShallow wells sunk by Maldhari herders in a depression to reach the sweet water lying over the saline layer
PhadTapi basin, MaharashtraDiversion bandhara system that spreads river water over blocks of fields in turn
Dong, Pat and Panam keniAssam, Jhabua in Madhya Pradesh, Wayanad in KeralaChannel, diversion and wooden-cylinder well systems of those regions

Modern rainwater harvesting

A modern system does one of two things with the rain: stores it for direct use, or sends it underground to recharge the aquifer.

  • A rooftop system runs from the catchment, which is the roof, through gutters and a down pipe to a first-flush device, then a filter, and finally to a storage sump or a recharge structure. The first flush is let out because the first rain washes dust, leaves and bird droppings off the roof.
  • Recharge pits, recharge trenches, dug-well recharge, recharge shafts and injection wells push water back into the ground where there is no space to store it above.
  • On a watershed, percolation tanks, check dams, nala bunds, contour bunding, contour trenches and gully plugging slow the runoff so that it soaks in instead of racing away.
  • Micro-irrigation, that is drip and sprinkler, saves water at the point of use, which matters because farming takes the largest share of India's water.

Schemes, bodies and policy

  • The Ministry of Jal Shakti was formed in 2019 by merging the ministry handling water resources, river development and Ganga rejuvenation with the ministry of drinking water and sanitation.
  • Jal Jeevan Mission, announced on 15 August 2019, works for a functional tap water connection in every rural household; Jal Jeevan Mission (Urban) is its town counterpart.
  • Atal Bhujal Yojana, launched in 2019 with World Bank assistance, funds community-led groundwater management in water-stressed blocks of seven states: Gujarat, Haryana, Karnataka, Madhya Pradesh, Maharashtra, Rajasthan and Uttar Pradesh.
  • Jal Shakti Abhiyan: Catch the Rain carries the slogan catch the rain, where it falls, when it falls.
  • Mission Amrit Sarovar, launched on 24 April 2022, aims to develop or revive 75 ponds in every district of the country.
  • The National Water Mission is one of the eight missions of the National Action Plan on Climate Change of 2008, and improving water use efficiency by 20 per cent is one of its stated goals.
  • The Central Ground Water Board assesses groundwater and the Central Ground Water Authority regulates its extraction. The National Water Policy has been issued three times, in 1987, 2002 and 2012.
  • Tamil Nadu was the first state to make rooftop rainwater harvesting compulsory in buildings, through an amendment to its building rules in 2003.

Rajendra Singh of Rajasthan, called the Waterman of India for reviving johads in the Alwar district, received the Ramon Magsaysay Award in 2001 and the Stockholm Water Prize in 2015.

Terms worth remembering

  • Aquifer: a rock layer that holds and yields groundwater; an unconfined aquifer is open to recharge from above, a confined one lies between impermeable layers.
  • Watershed: all the land draining to one common outlet, the unit on which soil and water conservation work is planned.
  • Virtual water: the water used to produce a good, which moves with the good when it is traded.
  • Water footprint: the total volume of fresh water used by a person, a crop or a country.
  • Grey water: used water from kitchens, baths and washing, fit for reuse in gardens and flushing after simple treatment.

Exam Point of View

The commonest question is a structure-to-state match: khadin, tanka, kund and johad to Rajasthan, zing to Ladakh, kuhl to Himachal Pradesh, zabo to Nagaland, bamboo drip irrigation to Meghalaya, ahar-pyne to south Bihar, surangam to Kerala, phad to Maharashtra and virda to Kutch. A second favourite is the scheme line: which ministry was formed in 2019, which agency funds Atal Bhujal Yojana, how many ponds per district under Amrit Sarovar, and the slogan of Catch the Rain. Expect one question on the parts of a rooftop system, usually on the purpose of the first-flush device, and one on the difference between storing rain and recharging an aquifer. The standard traps are swapping zing and kuhl, putting zabo in Meghalaya and bamboo drip irrigation in Nagaland, treating ahar as the channel and pyne as the reservoir, and crediting Maharashtra rather than Tamil Nadu with the first compulsory rooftop harvesting rule.

Important Facts

India's shareAbout 18 per cent of world population, about 4 per cent of world fresh water
KhadinJaisalmer, Rajasthan; credited to the Paliwal Brahmins, fifteenth century
ZaboKikruma village, Phek district, Nagaland; means impounding runoff
Bamboo drip irrigationKhasi and Jaintia hills of Meghalaya, for betel vine and black pepper
Ahar-PyneSouth Bihar; pyne is the channel, ahar the embanked reservoir
SurangamKasaragod district, Kerala; tunnel cut into laterite
Ministry of Jal ShaktiFormed in 2019 by merging two water related ministries
Jal Jeevan MissionAnnounced 15 August 2019, tap water to every rural household
Atal Bhujal Yojana2019, World Bank aided, seven states including Gujarat, Haryana and Rajasthan
Mission Amrit SarovarLaunched 24 April 2022, 75 ponds in every district
National Water MissionOne of eight missions under the National Action Plan on Climate Change, 2008
National Water PolicyIssued in 1987, 2002 and 2012
First state with compulsory rooftop harvestingTamil Nadu, 2003
Waterman of IndiaRajendra Singh; Magsaysay 2001, Stockholm Water Prize 2015

Practice MCQs on this topic

Q1.Environment & EcologyAsked in: Rajasthan · RSMSSB JE Mechanical (Degree) held on 13Easy

In Rajasthan, the tanka and khadin type is

  1. A.Of traditional water conservation techniques
  2. B.Of traditional war skills
  3. C.Of traditional folk dances
  4. D.Of traditional farming method
Show answer
Correct answer: A. Of traditional water conservation techniques

Explanation

The correct answer is A, of traditional water conservation techniques. A tanka is a covered underground tank, usually sunk in a courtyard or beneath a house in western Rajasthan, into which rain falling on the paved courtyard or the roof is led through a filter and stored for drinking right through the dry months. A khadin, worked out by the Paliwal Brahmins of Jaisalmer in the fifteenth century, is a long earthen embankment thrown across the lower slope of a rocky catchment; runoff collects behind it, soaks the soil, and a crop is raised on the moist bed after the standing water has drained away. Both therefore belong to the family of traditional water harvesting works of the desert, along with the kund, the johad and the baori. Option B is wrong because neither word carries any military sense. Option C is wrong because the folk dances of Rajasthan are Ghoomar, Kalbelia, Terah Taali and Chari. Option D is wrong because, although a khadin supports cropping, the structure itself is a water harvesting work and tanka has no farming meaning at all.

Q2.Environment & EcologyEasy

The zabo system of rainwater harvesting is practised in which state?

  1. A.Meghalaya
  2. B.Nagaland
  3. C.Mizoram
  4. D.Manipur
Show answer
Correct answer: B. Nagaland

Explanation

The correct answer is B, Nagaland. Zabo, a word that means impounding runoff, is practised around Kikruma village in the Phek district of Nagaland. Rain falling on a protected forest patch at the top of the hill is caught in ponds on the middle terrace, passed through cattle yards where it picks up manure, and then led to paddy fields lower down that also rear fish, so forest, water, livestock and crops are managed as one linked system. Option A is wrong because the harvesting practice of Meghalaya is bamboo drip irrigation, in which split bamboo pipes carry spring water drop by drop to betel vine and black pepper in the Khasi and Jaintia hills. Option C is wrong because Mizoram is known for its bamboo forests and jhum cultivation rather than for a named harvesting system of this kind. Option D is wrong because Manipur is identified in this topic with the Loktak lake and its floating phumdis, not with zabo.

Q3.Environment & EcologyEasy

Bamboo drip irrigation, in which split bamboo pipes carry spring water to the fields, is a traditional practice of

  1. A.Meghalaya
  2. B.Kerala
  3. C.Ladakh
  4. D.Bihar
Show answer
Correct answer: A. Meghalaya

Explanation

The correct answer is A, Meghalaya. In the Khasi and Jaintia hills, spring and stream water on a hill slope is tapped and carried through a network of split bamboo pipes, channels and diversion sticks that step the flow down the slope and finally release it drop by drop at the root of each betel vine or pepper plant. The system needs no cement, no pump and no power, and is one of the oldest micro-irrigation methods in the world. Option B is wrong because the traditional work of Kerala in this topic is the surangam, a horizontal tunnel cut into a laterite hill to tap seepage, besides the wooden-cylinder panam keni wells of Wayanad. Option C is wrong because Ladakh is associated with zing, the small tank that collects glacier melt water. Option D is wrong because south Bihar is the home of the ahar-pyne system of channels and embanked reservoirs.

Q4.Environment & EcologyMedium

In the traditional ahar-pyne system of south Bihar, what is a pyne?

  1. A.An embanked reservoir that stores runoff
  2. B.A diversion channel that carries water from a river
  3. C.A covered underground drinking water tank
  4. D.A stepped well cut down to the water table
Show answer
Correct answer: B. A diversion channel that carries water from a river

Explanation

The correct answer is B, a diversion channel that carries water from a river. In the old Magadh region of south Bihar the land slopes gently and the soil holds water poorly, so farmers cut long channels, the pynes, from the flood flow of rivers such as the Phalgu, Sakri and Morhar and led the water across the fields. Option A is wrong because the embanked catchment basin at the tail of a pyne is the ahar, a three-sided reservoir whose fourth side is the natural slope; mixing up ahar and pyne is the standard trap in this question. Option C is wrong because the covered underground drinking water tank is the tanka of western Rajasthan. Option D is wrong because the stepped well reaching down to the water table is the baori or vav of Rajasthan and Gujarat, of which Rani ki Vav at Patan is the best known. The ahar-pyne pair therefore works as channel plus reservoir together.

Q5.Environment & EcologyMedium

Zing, a small tank built to collect water from melting glaciers, is a traditional harvesting structure of

  1. A.Himachal Pradesh
  2. B.Uttarakhand
  3. C.Ladakh
  4. D.Sikkim
Show answer
Correct answer: C. Ladakh

Explanation

The correct answer is C, Ladakh. In the cold desert of Ladakh there is very little rain, so the water that matters is glacier melt. Guiding channels bring the melt water down from the snout of a glacier to a zing, a small tank near the fields, where it is held until the afternoon when the melt is strong enough to irrigate. A village water official, the churpun, divides the supply among the households. Option A is wrong because the gravity channel of Himachal Pradesh, in the Kangra region, is the kuhl, which carries glacier and stream water straight to terraced fields rather than storing it in a tank; swapping zing and kuhl is the commonest error here. Option B is wrong because Uttarakhand is associated with the guhl channels and the chal-khal ponds of the hills. Option D is wrong because Sikkim has a very heavy rainfall and is not identified with a named melt water tank of this kind.

Q6.Environment & EcologyHard

The surangam, a horizontal tunnel driven into a hill to tap seepage water, is found mainly in

  1. A.The laterite country of Kasaragod in Kerala
  2. B.The Banni grassland of Kutch
  3. C.The Tapi basin of Maharashtra
  4. D.The Alwar district of Rajasthan
Show answer
Correct answer: A. The laterite country of Kasaragod in Kerala

Explanation

The correct answer is A, the laterite country of Kasaragod in Kerala. A surangam is a tunnel about two metres high cut nearly level into the side of a laterite hill until it meets a seepage zone; the water that oozes out of the rock trickles along the floor of the tunnel and is collected in a pit outside, so the structure taps groundwater without any pumping. The same idea appears in the thurangam of the adjoining Dakshina Kannada area. Option B is wrong because the Banni grassland of Kutch has virdas, shallow wells dug by Maldhari herders in a depression to reach the thin layer of sweet water lying above the saline water. Option C is wrong because the Tapi basin has the phad system of diversion bandharas. Option D is wrong because Alwar is famous for johads, the small earthen check dams revived by Rajendra Singh and Tarun Bharat Sangh.

Q7.Environment & EcologyMedium

The Ministry of Jal Shakti was formed in 2019 by merging which two ministries?

  1. A.Agriculture, and Rural Development
  2. B.Water Resources, River Development and Ganga Rejuvenation, and Drinking Water and Sanitation
  3. C.Environment, Forest and Climate Change, and Earth Sciences
  4. D.Housing and Urban Affairs, and Panchayati Raj
Show answer
Correct answer: B. Water Resources, River Development and Ganga Rejuvenation, and Drinking Water and Sanitation

Explanation

The correct answer is B. In 2019 the Ministry of Water Resources, River Development and Ganga Rejuvenation was merged with the Ministry of Drinking Water and Sanitation to create a single Ministry of Jal Shakti, so that irrigation, river basins, groundwater, drinking water supply and sanitation would be handled by one ministry. It works through two departments, the Department of Water Resources, River Development and Ganga Rejuvenation and the Department of Drinking Water and Sanitation, and runs Jal Jeevan Mission, the Jal Shakti Abhiyan and Atal Bhujal Yojana. Option A is wrong because agriculture and rural development remain separate ministries, although watershed work is done under rural development. Option C is wrong because the environment and earth sciences ministries were not merged and deal with forests, pollution and weather services. Option D is wrong because urban water supply reaches cities through the urban affairs ministry but no such merger took place.

Q8.Environment & EcologyMedium

Atal Bhujal Yojana, the scheme for community-led groundwater management in water-stressed blocks, is assisted by

  1. A.The Asian Development Bank
  2. B.The World Bank
  3. C.The New Development Bank
  4. D.The International Monetary Fund
Show answer
Correct answer: B. The World Bank

Explanation

The correct answer is B, the World Bank. Atal Bhujal Yojana, launched in 2019 under the Ministry of Jal Shakti, is a central sector scheme part funded by the World Bank. It works in water-stressed blocks of seven states, namely Gujarat, Haryana, Karnataka, Madhya Pradesh, Maharashtra, Rajasthan and Uttar Pradesh, and its distinguishing feature is that gram panchayats prepare water security plans and money flows to them as an incentive for measured improvement in groundwater behaviour rather than for construction alone. Option A is wrong because the Asian Development Bank funds many Indian irrigation and urban water projects but not this scheme. Option C is wrong because the New Development Bank, set up by the BRICS countries with its headquarters at Shanghai, is not the partner here. Option D is wrong because the International Monetary Fund lends for balance of payments support and does not fund development schemes of this kind at all.

Q9.Environment & EcologyEasy

Mission Amrit Sarovar, launched in 2022, aims to develop or rejuvenate how many ponds in every district?

  1. A.25
  2. B.50
  3. C.75
  4. D.100
Show answer
Correct answer: C. 75

Explanation

The correct answer is C, 75. Mission Amrit Sarovar was launched on 24 April 2022, National Panchayati Raj Day, as part of the celebration of seventy-five years of independence, and the number 75 in the target of seventy-five ponds in every district of the country comes from that anniversary. Each amrit sarovar is planned to hold about ten thousand cubic metres of water, and the work is done by converging funds already available under schemes such as the rural employment guarantee programme and the watershed component of the rural development programmes. Option A, option B and option D are wrong simply because they are not the announced figure; twenty-five, fifty and one hundred are the usual distractors for a target of this kind. Remembering the link between the number 75 and the anniversary of independence is the quickest way to hold this fact.

Q10.Environment & EcologyHard

The National Water Mission is one of the eight missions under which of the following?

  1. A.The National Action Plan on Climate Change
  2. B.The National Water Policy, 2012
  3. C.The Namami Gange Programme
  4. D.The National Rural Drinking Water Programme
Show answer
Correct answer: A. The National Action Plan on Climate Change

Explanation

The correct answer is A, the National Action Plan on Climate Change. The plan, released in 2008, set up eight national missions, among them the National Solar Mission, the National Mission for Enhanced Energy Efficiency, the National Water Mission, the National Mission for Sustaining the Himalayan Ecosystem, the National Mission for a Green India, the National Mission for Sustainable Agriculture, the National Mission on Sustainable Habitat and the National Mission on Strategic Knowledge for Climate Change. The water mission aims at integrated water resources management and at raising water use efficiency by twenty per cent. Option B is wrong because the National Water Policy is a statement of principles, not a parent of missions, though it also stresses efficiency. Option C is wrong because Namami Gange is a river cleaning programme for the Ganga basin. Option D is wrong because the rural drinking water programme supplied village water and was later folded into Jal Jeevan Mission.

Q11.Environment & EcologyMedium

Which state was the first in India to make rooftop rainwater harvesting compulsory in buildings?

  1. A.Maharashtra
  2. B.Tamil Nadu
  3. C.Gujarat
  4. D.Rajasthan
Show answer
Correct answer: B. Tamil Nadu

Explanation

The correct answer is B, Tamil Nadu. Faced with a steep fall in the water table around Chennai, the state amended its building rules in 2003 to require a rainwater harvesting structure in buildings, and it is cited as the first state in the country to make such harvesting compulsory. Other states and the model building bye-laws later carried similar provisions, and many municipal corporations now link building plan approval to a harvesting structure. Option A is wrong because Maharashtra, though an early mover on watershed work through the Pani Panchayat and Jalyukt Shivar efforts, was not first with this building rule. Option C is wrong because Gujarat is linked in this topic with the Sardar Sarovar canal network and the revival of stepwells and virdas. Option D is wrong because Rajasthan is the home of the traditional desert structures such as the tanka, the kund and the johad rather than of the first legal mandate.

Frequently Asked Questions

What is the difference between water conservation and rainwater harvesting?

Water conservation is the wider idea of using water so that withdrawal does not exceed recharge, and it includes efficient irrigation, reuse and leak control. Rainwater harvesting is one method within it: collecting rain from a roof or a catchment and either storing it or using it to recharge the aquifer.

Which state is the khadin system associated with?

Rajasthan, and within it the Jaisalmer region. A khadin is an earthen embankment across the lower slope of a rocky catchment that holds runoff, soaks the soil and lets a crop be raised on the moist bed. It is credited to the Paliwal Brahmins of the fifteenth century.

What is the zabo system and where is it practised?

Zabo, which means impounding runoff, is practised at Kikruma in Nagaland. Rain falling on forested hill tops is caught in ponds, passed through cattle yards where it picks up manure, and then led to terraced paddy fields that also rear fish, so water, soil, livestock and crops form one system.

Why is a first-flush device used in rooftop rainwater harvesting?

The first rain of a shower washes dust, leaves and droppings off the roof, so that water is the dirtiest. A first-flush device lets this initial quantity run out to waste and only the cleaner water that follows reaches the filter and the storage tank, which keeps the stored water fit for use.

Which state first made rooftop rainwater harvesting compulsory?

Tamil Nadu, which amended its building rules in 2003 to require rainwater harvesting structures in buildings. Many other states and the model building bye-laws have since made similar provisions, but Tamil Nadu is the answer expected for the first such mandate.

Who is called the Waterman of India?

Rajendra Singh of Rajasthan, who revived johads and dried streams in the Alwar region through the organisation Tarun Bharat Sangh. He received the Ramon Magsaysay Award in 2001 and the Stockholm Water Prize in 2015.
